Product Details:
Place of Origin: CHINA
Brand Name: KERSTERN
Certification: ISO9001
Model Number: KMT OMT
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Standard seaworthy export packing or as customer demands
Delivery Time: 7-15 work days
Payment Terms: T/T, Western Union
Supply Ability: 10000PCS /Year
Contact Now

Detail Information
Usage: Construction Machine Commutation: Brush
Application: Mobile Machine Motor Type: Orbital Motor
The Sample Service: Samples Are Available Pressure: High Pressure
High Light:

KMT Danfoss Orbital Motor

,

Mobile machine Danfoss Orbital Motor

,

danfoss gerotor motor ISO9001

Product Description

Design and construction Danfoss Orbital Motor final inspection


Advantages:
Low pressure start;
Reinforced shaft seal;
High startup torque and ability to withstand significant back pressures;
The ability totransferaxial and radial loads;
Compact volume and easy installation.

Introduction:
•  Very Compact Package
•  Higher Output Torque
•  Improved Efficiency
•  Durable Design and Construction
•  Quiet and Smooth Operation
•  Shuttle Valve for Reliable Drive Lubrication
•  Rating Compatible with Medium Duty Pumps
•  Patented Technology


product description:

Product Name

OMT/KMT Orbit hydraulic motor
Feature

1. Advanced Gerolor gear manufacturing device, which make the operation are stable and reliable
2. Low noise,high efficiency and long working life
3. small volume and easy to install
Material
Cast Iron
OEM/ODM
Customization Service Provided
MOQ
1PC
Package
ODM /OEM/1pc/carton
Delivery time
Within 1 to 7 days after receiving the payment

1. weight
160-520KG
2. power
90-175KW
3. Direction of rotation
4. reversible
Overall life
5. high Features
high volume efficiency and mechanical efficiency
6. Certification
ISO9001,

Home > Product Center > KM2 Series Hydraulic Motor
Product Center
KMM Series Hydraulic Motor
KM1 Series Hydraulic Motor
KM2 Series Hydraulic Motor
ZKM2 Series Hydraulic Motor
KM3 Series Hydraulic Motor
KM4 Series Hydraulic Motor
KM5 Series Hydraulic Motor
KM5S Series Hydraulic Motor
KM6 Series Hydraulic Motor
KMER Series Hydraulic Motor
KMT Series Hydraulic Motor
KMV Series Hydraulic Motor
ZD Series Hydraulic Motor
Other products ----- Keystone steering units
More classification

KMT Series Hydraulic Motor

Displacement(ml/r) 250 315 400 500 630 800

flow

(LPM)

 cont. 125 125 125 125 125 125
int. 150 150 150 150 150 150

speed

(RPM)

 cont. 495 380 302 237 196 154
int. 592 458 364 284 233 185

pressure

(MPA)

 cont. 20 20 18 16 14 12.5
int. 24 24 21 18 16 13

torque

(N*M)

 cont. 727 962 1095 1245 1318 1464
int. 888 1154 1269 1409 1498 1520

output power

(KW)

 cont. 34.5 35 31 29 25 22
int. 40 40 35 35 27.5 27

Packing:

KMT Mobile Machine Danfoss Orbital Motor Final Inspection Danfoss Gerotor Motor ISO9001 0

transportation:
KMT Mobile Machine Danfoss Orbital Motor Final Inspection Danfoss Gerotor Motor ISO9001 1


FAQ:

1.  who are we?
We are based in Jining, China, start from 2003.
2.  how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.  what can you buy from us?
Hydraulic motor
4.  How long is the Warranty?
One-year warranty
5.  What is your payment terms?
Re: 100% in advance, long-term dealer 30% in advance, 70% beofre shipping.
6.  How about the delivery time?
Normal Models within 2 days, unusual models and bulk order within 5-10 days.
