Orbital KMT Dynamic White Hydraulic Motors For Construction Machine

Product Details:
Place of Origin: CHINA
Brand Name: KERSTERN
Certification: ISO
Model Number: KMT OMT
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: Negotiable
Packaging Details: Standard seaworthy export packing or as customer demands
Delivery Time: 7-15 work days
Payment Terms: T/T, L/C
Supply Ability: 100000PCS /Year

Detail Information

Usage: Construction Machine Commutation: Brush
Application: Mobile Machine Motor Type: Orbital Motor
The Sample Service: Samples Are Available Pressure: High Pressure
High Light:

Orbital dynamic hydraulic motors

,

KMT dynamic hydraulic motors

,

danfoss white motors ISO9001

Product Description

design and construction Danfoss Orbital Motor final inspection


Introduction:
•  Very Compact Package
•  Higher Output Torque
•  Improved Efficiency
•  Durable Design and Construction
•  Quiet and Smooth Operation
•  Shuttle Valve for Reliable Drive Lubrication
•  Rating Compatible with Medium Duty Pumps
•  Patented Technology


product description:



Product Name

OMT/KMT Orbit hydraulic motor

Feature

1. Advanced Gerolor gear manufacturing device, which make the operation are stable and reliable
2. Low noise,high efficiency and long working life
3. small volume and easy to install

Material
Cast Iron
OEM/ODM
Customization Service Provided
MOQ
1PC
Package
ODM /OEM/1pc/carton
Delivery time
Within 1 to 7 days after receiving the payment


Danfoss Orbital Motor
Displacement80cc,100cc,125cc,160cc,200cc,250cc,315cc,400cc,475cc
Flange:E2: 2-Ø13.5 Rhomb-flange Ø106.4,pilot Ø82.5×6.3
E4: 4-Ø13.5 Rhomb-flange Ø106.4,pilot Ø82.5×6.3
F6: 6-Ø13.5 Rhomb-flange Ø106.4,pilot Ø82.5×2.6
W: 4-Ø13.5 Wheel-flange Ø160 ,pilot Ø125×8
E2B: 2-Ø14.3 Rhomb-flange Ø146.05,pilot Ø101.6×9.4
SP: 4-Ø11.5 Square-flange Ø106.4,pilot Ø82.5×6.3
D: 4-Ø11 Circle-flange Ø125 ,pilot Ø100×6
E: 4-Ø13.5 Square-flange Ø127 ,pilot Ø101.6×6.3
Output Shaft:A: Shaft Ø25 , parallel key 8×7×32
B: Shaft Ø32 , parallel key 10×8×45
D:Shaft Ø25.4 , parallel key6.35×6.35×25.4
G: Shaft Ø31.75 ,parallel key 7.96×7.96×31.75
F: Shaft Ø31.75 ,splined tooth 14-DP12/24
FD: Long Shaft Ø31.75 ,splined tooth 14-DP12/24
SL: shaft Ø34.85,Splined key 6-34.85×28.14×8.64
T1: Cone-shaft Ø35 ,parallel key B6×6×20
T3: Cone-shaftØ31.75 ,parallel key 7.96×7.96×31.75
S1: Shaft Ø25.4 ,splined tooth SAE 6B
I: Sub-shaft Ø22,splined tooth 13-DP16/32
Port and drain port:D: G1/2 Manifold Mount 2-M10 , G1/4
M: M22×1.5 Manifold Mount 2-M10 , M14×1.5
S: 7/8-14UNF O-ring manifold 2-3/8-16 , 7/16-20UNF
P: 1/2-14NPTF manifold 2-3/8-16UNC , 7/16-20UNF


1. weight
160-520KG
2. power
90-175KW
3. Direction of rotation
4. reversible
Overall life
5. high Features
high volume efficiency and mechanical efficiency
6. Certification
ISO9001,CCS,KR,NK

Payment terms:
1, Small amount accept Western Union
2, Large orders We usually accept T/T(with 30% deposit,the balance before shipment)


Orbital KMT Dynamic White Hydraulic Motors For Construction Machine 0


Packing:
Orbital KMT Dynamic White Hydraulic Motors For Construction Machine 1

transportation:
Orbital KMT Dynamic White Hydraulic Motors For Construction Machine 2


FAQ:


2.  how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.  what can you buy from us?
Hydraulic motor

4.  How long is the Warranty?
One-year warranty.

5.  What is your payment terms?
Re: 100% in advance, long-term dealer 30% in advance, 70% beofre shipping.

6.  How about the delivery time?
Normal Models within 2 days, unusual models and bulk order within 5-10 days.
