High Torque Hydraulic Wheel Motor with Max Pressure of 205 Bar and Max Flow of 150 LPM for Heavy Duty Applications
High Torque Hydraulic Wheel Motor with Max Pressure of 205 Bar and Max Flow of 150 LPM for Heavy Duty Applications
High Torque Hydraulic Wheel Motor with Max Pressure of 205 Bar and Max Flow of 150 LPM for Heavy Duty Applications High Torque Hydraulic Wheel Motor with Max Pressure of 205 Bar and Max Flow of 150 LPM for Heavy Duty Applications

High Torque Hydraulic Wheel Motor with Max Pressure of 205 Bar and Max Flow of 150 LPM for Heavy Duty Applications

Product Details:
Place of Origin: CHINA
Brand Name: KERSTERN
Certification: ISO9001
Model Number: 6000 series KM6B
Payment & Shipping Terms:
Minimum Order Quantity: 1 PC
Price: According to order quantity
Packaging Details: Carton and Wooden box
Delivery Time: 7 work days
Supply Ability: 10000pcs per month
Contact Now

Detail Information
Motor Type: Orbital Motor Condition: New
Usage: Drilling Rig, Excavator Transport Package: Wooden Box/Carton Box
Application Machine: Mini Excavator/Weeder/Garbage Truck Commutation: Brush
Highlight:

High torque hydraulic wheel motor

,

Hydraulic wheel motor 205 bar

,

Heavy duty hydraulic wheel motor

Product Description

Applications
These motors can be used in industrial machines (e.g. conveyors), mining machinery (e.g. drills, winches), working machines (e.g. bulldozers, crushers) and in shipbuilding industry (e.g. control systems, propellers) etc.



Advantages
1. Low start-up pressure;
2. Shaft seal can bear high back pressure;
3. The motor can be used in parallel or series configuration;
4. Distribution system can meet the requirements of low noise units;
5. Compact volume and easy installation;
6. High torque.



KM6B Brake motor



KM6B motor is KM6 brake motor with multi-disc brake that is released by a hydraulic pressure ,and has good brake performance ,the motor has same work performance as BM6 when the brake is released.


Main Specification


Displacement   195 245 310 395 490 625
(ml/r)


Release pressure   25 25 25 25 25 25
(bar)


BrakeTorque (NM) <=800 <=800 <=800 <=800 <=800 <=800

Max pressure (bar) 205 205 205 205 170 140

Max Flow(LPM) 150 150 150 150 150 150








Note:


1, Don’t work over the max pressure


2, The drain port must be connected to the return circuit 3, Don’t brake when the motor is dynamic status


4, If the system has pilot pump,use pilot oil to open the brake, otherwise , the working pressure don’t exceed 150 bar.

5, The oil temperature don’t exceed 80℃

6,Oil recommended: Anti-wear hydraulic oils , viscosity at least 13cSt in working .





High Torque Hydraulic Wheel Motor with Max Pressure of 205 Bar and Max Flow of 150 LPM for Heavy Duty Applications 0





Packing:
High Torque Hydraulic Wheel Motor with Max Pressure of 205 Bar and Max Flow of 150 LPM for Heavy Duty Applications 1

FAQ:

1. who are we?
We are based in Jining China, start from 2003
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3. what can you buy from us?
Hydraulic motor
4. How long is the Warranty?
One-year warranty.
5. What is your payment terms?
Re: 100% in advance, long-term dealer 30% in advance, 70% beofre shipping.
6. How about the delivery time?
Normal Models within 2 days, unusual models and bulk order within 5-10 days.
