Detail Information
Model:	OMS BM5	Type:	Hydraulic Motor
1Structural Style:	Orbital	Application:	Construction Machinery And Agricultural Machinery
Processing:	Forging&cutting	Flange:	Square And Rhombus Flange
Highlight:	OMS80 Orbit Hydraulic Motor , Cast Iron Orbit Hydraulic Motor , Forging two speed hydraulic motor

Product Description

Cast Iron Hydraulic Orbital Motors

Model:	OMS BM5	Brand:	KERSTERN
Type:	Hydraulic Motor	Place Of Origin:	China
Certification:	ISO9001	Material:	Cast Iron
Motor Shafts:	Straight, Splined And Tapered	Power:	Hydraulic Oil
Structural Style:	Cycloid	Processing:	Forging&cutting
Application:	Construction Machinery And Agricultural Machinery	Flange:	Square And Rhombus Flange
Package:	Standard	Color:	As Requests
Warranty:	One Year

Economical Hydraulic Orbit Motor OMS BM5 with Variety of Mounting Flanges, Shafts, Ports

Sauer Eaton Orbit Hydraulic Motor 0

Descrition:

Compact in design with spool valving and Geroler
Imported high pressure capacity shaft seal
Wide variety of mounting flanges, shafts, ports
and speed provides design flexibility

Direction of shaft rotation and speed can be controlled easily and smoothly
Best combination of efficiency and economy in medium duty applications

Applications: Hydraulic system, engineering machine, industry machine

Brand:	KERSTERN	Material:	Cast Iron
Color:	As Requets	Condition:	New
Warranty:	One Year	Type:	Orbit Motor
Place Of Origin:	China	Certification:	ISO9001
Motor Shafts:	Straight, Splined And Tapered	Power:	Hydraulic Oil
Structural Style:	Cycloid	Processing:	Foring & Cutting
Application:	Engineering Mahinery And Agricultural Machinery	Motor Flange:	Square And Rhombus Flange
Package:	Standard Package

250 / 280 / 500 ml/r Industrial / Engineering Geroler Hydraulic Orbit Motor OMS/BM5

Applications: Hydraulic system, engineering machine, industry machine

Descrition:

Compact in design with spool valving and Geroler
Imported high pressure capacity shaft seal
Wide variety of mounting flanges, shafts, ports
and speed provides design flexibility

Direction of shaft rotation and speed can be controlled easily and smoothly
Best combination of efficiency and economy in medium duty applications

Specifications:

Displacement(ml/r)		80	100	125	160	200	250	280	305	400	500
Flow(LPM)	Cont.	75	75	75	75	75	75	75	75	75	75
Flow(LPM)	Int..	85	95	95	115	115	115	115	115	130	130
Speed(RPM)	Cont.	850	675	552	430	345	276	246	226	180	144
Speed(RPM)	Int..	956	855	700	660	529	423	378	347	308	246
Pressure(Mpa)	Cont.	17.5	17.5	17.5	17.5	17.5	17.5	17.5	15	15	12
Pressure(Mpa)	Int..	28	28	28	25	25	25	25	21	17.5	15
Torque(N*m)	Cont.	178	223	278	356	445	557	592	580	715	720
Torque(N*m)	Int..	285	356	445	509	636	755	779	763	840	860

Note:

1.Continuous data:The Max.Value of operating motor continuously.

2.Intermittent Data:The Max.Value of operating motor in 6 seconds per minute.

3.A simultaneous max. RPM and max. Pressure is not recommended.

4.The Conversion Factors is on the page 4, consult it please

5.Optimum operating situation should be at the 1/3 ~ 2/3 of the continuous operating situation.

Tag:

Product Details:
Place of Origin:	CHINA
Brand Name:	KERSTERN
Certification:	ISO9001
Model Number:	OMS80 BM5-80
Payment & Shipping Terms:
Minimum Order Quantity:	1 pc
Price:	According to order quantity
Packaging Details:	Carton and wooden box
Delivery Time:	7 work days
Supply Ability:	10000 pcs per month

Sauer Eaton Orbit Hydraulic Motor

OMS80 Orbit Hydraulic Motor

Cast Iron Orbit Hydraulic Motor

Forging two speed hydraulic motor

spool valve motor

high efficiency motor

geroler motor

Jining Keystone Hydraulic Co.,Ltd

Professional manufacturer of Hydraulic Orbital motors, valves and Steering unit
