KM6 Variable High Torque Hydraulic Motor Wheel Motor Casting Steel 1875N
|
Product Details:
|
|
| Place of Origin: | CHINA |
|---|---|
| Brand Name: | KERSTERN |
| Certification: | ISO9001 |
| Model Number: | OME BMER KMER series |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1 pc |
| Price: | According to order quantity |
| Packaging Details: | Carton and wooden box |
| Delivery Time: | 7 work days |
| Supply Ability: | 10000 pcs per month |
|
Detail Information |
|||
| Product Name: | Hydraulic Motor/orbital Hydraulic Motor | Displacement: | 125-750cc |
|---|---|---|---|
| Model: | BMER KMER OMER | Warranty: | One Year |
| Hydraulic Fluid: | Mineral Oil | Standard Or Non Standard: | Standard |
| High Light: | Exceptional Torque Output Hydraulic Motors,High Performance Hydraulic Motors,High Torque Output Hydraulic Motors |
||
Product Description
Product introduction:
High Torque Motors A high torque hydraulic orbital motor is a very effective device for converting hydraulic fluids into mechanical motion. It generally uses an internal gear design one gear set inside another-in order to convey fluid through the system. The gears are manufactured in a variety of types; some have teeth, while others have rollers.
| Model: | KMER | Brand: | KERSTERN |
|---|---|---|---|
| Type: | Hydraulic Motor | Place Of Origin: | China |
| Certification: | ISO 9001 | Material: | Cast Iron |
| Motor Shafts: | Straight, Splined And Tapered | Power: | Hydraulic Oil |
| Structural Style: | Cycloid | Processing: | Forging&cutting |
| Application: | Construction Machinery And Agricultural Machinery | Flange: | Square And Rhombus Flange |
| Package: | Standard | Color: | As Requests |
| Warranty: | One Year |
Displacement 125-750cc High Torque Hydraulic Motor With Custom Color
Descrition:
Applications: Arieal working platform, Excavator, engineering machine, industry machine
Specifications:
| Displ.(cc/r) | 125 | 160 | 200 | 230 | 250 | 300 | |
| Flow(LPM) | Rated | 45 | 60 | 70 | 70 | 75 | 80 |
| Max | 60 | 75 | 85 | 85 | 90 | 95 | |
| Speed(RPM) | Rated | 350 | 365 | 320 | 300 | 295 | 245 |
| Max | 500 | 465 | 420 | 360 | 350 | 320 | |
| Pressure(Bar) | Rated | 21 | 21 | 21 | 21 | 21 | 21 |
| Max | 25 | 25 | 25 | 25 | 25 | 25 | |
| Torque(Nm) | Rated | 320 | 435 | 520 | 610 | 700 | 800 |
| Max | 400 | 520 | 600 | 700 | 800 | 950 | |
| Weight | 13 | 13.7 | 14.3 | 14.8 | 15.2 | 15.6 |
|
